Sigenergy · Single Phase
Single Phase Hybrid Inverter
Sigen Energy Controller · 5.0kW to 12.0kW
The Smart Core That Runs Your Whole Solar and Battery System
The single phase Sigen Energy Controller manages power between your solar panels, battery and the grid, delivering up to 98.0% efficiency and 0 millisecond backup switchover when paired with a Sigen Energy Gateway and Sigen Battery. Available from 5.0kW to 12.0kW for single-phase homes.
Key Features & Benefits
EMS-Integrated Intelligent Management
Coordinates precisely with the battery and solar for precision control over output.
High DC/AC Ratio Compatibility
Supports up to a 2.0 DC/AC ratio, so an oversized solar array is not wasted.
200% Peak Off-Grid Output
Provides an instant power boost for 10 seconds during a blackout, helping larger loads start when required.
Up to Four MPP Trackers
Draws maximum output from split, shaded or multi-orientation solar arrays, scaling from 2 trackers on smaller models to 4 on larger models.
Technical Specifications
- Power Range
- 5.0, 6.0, 8.0, 10.0 and 12.0kW SP models
- Maximum Efficiency
- Up to 98.0%
- Backup Switchover
- 0 milliseconds*
- Battery Compatibility
- 1 to 6 modules, 300-600V range
- MPP Trackers
- 2 to 4, depending on model
- Operating Temperature
- -30°C to 60°C
- Ingress Protection
- IP66
AS/NZS 4777.2:2020+A1:2024 certified. *0 millisecond backup switchover requires a Sigen Energy Gateway and Sigen Battery.
